Description
1 – Channel Online Monitoring System
The A3900 is a simple one channel online monitoring system. Measured value is displayed on the front panel and can be transferred to the control system through 4-20 mA current loop output. Green, yellow and red LEDs informs you about the machine/bearing vibration state. The A3900 unit includes one programmable output “ALARM” relay.
Key Features
- 1 channel, selectable value: [mm/s] / [ips] / [g]
- Display of actual value
- 4-20 mA current loop output
- Relay output
- Easy PC setting
Technical Specifications
| Inputs | ICP® for acceleration sensor. Input is able to process signal with maximum voltage ±5 V |
| Outputs | 4- 20 mA current loop (selectable active/passive) with setting of range of measured unit |
| Measuring Ranges | 0 – 99.9 g, 0 – 999 mm/s (by sensor sensitivity, input signal: max. ±5 V) |
| Frequency Bands | [ g ] 0,8 Hz – 16 kHz [ g ] 5 kHz – 16 kHz [ mm/s ], [ ips ] 10 Hz – 1 kHz Frequency ranges could be changed under request. |
| Sensor | accelerometer, ICP® powered |
| LEDs | Vibration state indication according to defined vibration limits Power indication ICP® error indication |
| Powering | 20 – 28 V DC (70mA/24V DC), external current loop supply (10-30V DC) |
| Dimensions | 90 x 53 x 58 mm |
| Weight | 130 g |
|
Protection
|
IP 20 |
